将同一类型的端口划分到同一端口组内，通过操作端口组就达到了操作所有端口，从而节约了时间，提升了工作效率；下面将讲解华为交换机端口组的配置具体配置步骤和相关命令。

进入到交换机，然后进入到system-view模式，创建端口组1，该组内端口都配置为access模式，且默认vlan为10，具体命令如下：

system-view Enter system view, return user view with Ctrl+Z.[Huawei]port-group 1 [Huawei-port-group-1]group-member Ethernet 0/0/1 to Ethernet 0/0/10[Huawei-port-group-1]port link-type access[Huawei-Ethernet0/0/1]port link-type access[Huawei-Ethernet0/0/2]port link-type access[Huawei-Ethernet0/0/3]port link-type access[Huawei-Ethernet0/0/4]port link-type access[Huawei-Ethernet0/0/5]port link-type access[Huawei-Ethernet0/0/6]port link-type access[Huawei-Ethernet0/0/7]port link-type access[Huawei-Ethernet0/0/8]port link-type access[Huawei-Ethernet0/0/9]port link-type access[Huawei-Ethernet0/0/10]port link-type access[Huawei-port-group-1]port default vlan 10[Huawei-Ethernet0/0/1]port default vlan 10[Huawei-Ethernet0/0/2]port default vlan 10[Huawei-Ethernet0/0/3]port default vlan 10[Huawei-Ethernet0/0/4]port default vlan 10[Huawei-Ethernet0/0/5]port default vlan 10[Huawei-Ethernet0/0/6]port default vlan 10[Huawei-Ethernet0/0/7]port default vlan 10[Huawei-Ethernet0/0/8]port default vlan 10[Huawei-Ethernet0/0/9]port default vlan 10[Huawei-Ethernet0/0/10]port default vlan 10[Huawei-port-group-1]quit

创建端口组2，该组内端口都配置为access模式，且默认vlan为20，具体命令如下：

[Huawei]port-group 2 [Huawei-port-group-2]group-member Ethernet 0/0/11 to Ethernet 0/0/22[Huawei-port-group-2]port link-type access[Huawei-Ethernet0/0/11]port link-type access[Huawei-Ethernet0/0/12]port link-type access[Huawei-Ethernet0/0/13]port link-type access[Huawei-Ethernet0/0/14]port link-type access[Huawei-Ethernet0/0/15]port link-type access[Huawei-Ethernet0/0/16]port link-type access[Huawei-Ethernet0/0/17]port link-type access[Huawei-Ethernet0/0/18]port link-type access[Huawei-Ethernet0/0/19]port link-type access[Huawei-Ethernet0/0/20]port link-type access[Huawei-Ethernet0/0/21]port link-type access[Huawei-Ethernet0/0/22]port link-type access [Huawei-port-group-2]port default vlan 20[Huawei-Ethernet0/0/11]port default vlan 20[Huawei-Ethernet0/0/12]port default vlan 20[Huawei-Ethernet0/0/13]port default vlan 20[Huawei-Ethernet0/0/14]port default vlan 20[Huawei-Ethernet0/0/15]port default vlan 20[Huawei-Ethernet0/0/16]port default vlan 20[Huawei-Ethernet0/0/17]port default vlan 20[Huawei-Ethernet0/0/18]port default vlan 20[Huawei-Ethernet0/0/19]port default vlan 20[Huawei-Ethernet0/0/20]port default vlan 20[Huawei-Ethernet0/0/21]port default vlan 20[Huawei-Ethernet0/0/22]port default vlan 20[Huawei-port-group-2]quit

在system-view下输入display current-configuration查看各端口配置是否与端口组配置一致。
